• Use two motorized linear slides (one for each side) with precise stepper motors and integrated lead screws, each slide holding four HDMI male connectors aligned to the PCB. • Each slider will be guided by rails and alignment keys to ensure all connectors engage and disengage smoothly, with attention to required 25 mm spacing and correct orientation. • Low insertion forces per connector are managed by the slider’s controlled movement, while guide pins and keying features prevent any misalignment or strain on the PCB. • Self-locking engagement latches or magnetic snaps can secure the connectors during operation. • Recommended components include ready-to-use electric actuators with built-in stepper motors and position feedback, with options offering ±0.02 mm repeatability and 50 mm stroke lengths—well suited for HDMI connector duty.
